copper conductor PVC insulated PVC sheathed electric wire from China manufacturer - Zhengzhou Aobest Electronic Technology Co., Ltd.

copper conductor PVC insulated PVC sheathed electric wire

Price:	0.5~66.0 USD
Payment Terms:	T/T,L/C,WU,
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: BVV

Production Capacity: 50000m/week

Delivery Date: 15days for one container

Type: electric wire

Jacket: PVC

Brand Name: Aobest

construction: CU/PVC/PVC

Means of Transport: Ocean,Land,Air,

Packing: standard roll or wooden dru...

Application: indoor/outdoor

Insulation Material: PVC

Conductor Material: Copper

Color: red/black/blue/yellow/green

1. PVC wire
2. multicore wire
3. 0.5mm2,0.75mm2,1mm2,1.5mm2,2.5mm2,4mm2,6mm2
4. red/white/brown/black/blue/yellow/green
5. Made in China

copper conductor PVC insulated PVC sheathed electric wire

Aobest Company cable Features:

1 Excellent Insulating Ability for Safe Use

2 High Reliability and Stability

3 Strongly Water-proof and Liquid-Proof

4 Strongly Protect the Transmission against the Interference of Electromagnetic Wave

5 Multi-Strands Conductor Design for High Performance

6 Color in White, Black or as per Your Requirements

7 Ratingtemperature:75°C

8 Nominalvoltage:300V/300V

Applications:

1 Machine Tool Manufacture Industry

2 Full Set of Equipment Installation Project

3 Power Plant System

4 Central Heating and Air-Condition System

5 Office Automation Equipments Application

some sizes of the cables

CONDUCTOR				INSULATION		JACKET		MAX COND RESISTENCE (20 Ω/KM)
Cross section (mm²)	Core structure (No./mm)	Dia (mm)	Core	Insulation Thinckness (mm)	O.D (mm)	Jacket Thickness (mm)	O.D (mm)	MAX COND RESISTENCE (20 Ω/KM)
0.75	24/0.20	1.13	2	0.61	2.35	0.80	6.30	26.7
			3	0.61	2.35	0.82	6.70
			4	0.61	2.35	0.82	7.30
			5	0.61	2.35	0.93	8.20
1	32/0.20	1.31	2	0.60	2.50	0.80	6.60	20.0
			3	0.60	2.50	0.86	7.10
			4	0.60	2.50	0.93	7.90
			5	0.60	2.50	0.93	8.60
1.5	30/0.25	1.58	2	0.71	3.00	0.80	7.60	13.7
			3	0.71	3.00	0.92	8.30
			4	0.71	3.00	1.08	9.40
			5	0.71	3.00	1.15	10.40
2.5	49/0.25	2.02	2	0.82	3.65	1.00	9.30	8.21

Many other PVC/XLPE power cable,rubber cable,ABC cable,control cable,bare conductor can be produced.
More info needed, pls contact me freely.
