low voltage xlpe insulated pvc sheathed power cable

Price:	1.0~66.0 USD
Payment Terms:	T/T
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: YJV

Production Capacity: 50000m/week

Delivery Date: 15days for one container

Type: XLPE power cable

Jacket: PVC

Brand Name: Aobest

conductor: Copper

voltage: 0.6/1KV

Means of Transport: Ocean

Packing: standard wooden drum

Application: Underground

Insulation Material: XLPE

Conductor Material: Copper

Color: red/black/blue/yellow/green

warranty: 20years

1. XLPE underground cable
2. golden supplier
3. factory price
4. first-class service
5. strict QC

0.6/1kv xlpe insulated pvc sheathed power cable

Application:

The Aobest 0.6/1kv xlpe insulated pvc sheathed power cable is designed for application in electricity distribution system or fixed installation with rated voltage up to and including0.6/1kV~26/35kV

Max. continous operating temperature of conductor:90°C

Max.short-circuitt emperature of conductor :≤ 250°C(5s maximum duration)

The ambient temperature under installation:+ 0°C

The bending radius: not less than 15 times of diameter of the cable.

Technical Data

1.Voltage :300/500V,450/750v

2.Standard: IEC60502,BS6346,BS7889,BS5467,BS6724,

AS/NZS5000.1,VDE0271,GB/T12706.

3.conductor:stranded copper(/Aluminum)conductor for single-core

shaped conductors conductors for multi-cores

4.insulation: XLPE

5.sheath: PVC/PE

6.armour: unarmoured /steel tape / steel wire/ aluminumwire

1.Cores: 0.6/1kV :1,2,3,4,(3+1),5,(4+1),(3+2)

6~35kV : single core or3cores

2.Cross section area:1.5~800mm2

3.Color:black or as per requirement

4.Certification:ISO9001,ISO14001,SGS, CCC,etc.

5.OEM welcome.

Part of the XLPE power cable types

Cores	Nominal cross-section area mm²	Nominal thickness of insulation mm	Thickness of outer sheath mm	Overall diameter mm	A.C.test voltage(V) KV/5min	Maximum resistance of conductor (Ω/km)	Insulation resistance M(Ω/km)	Weight kg/km	Length m
3C	2.0 3.5 5.5 8 14 22 38 60 100 150 200 250 325	0.75 0.75 0.75 1.14 1.14 1.14 1.40 1.40 1.40 1.64 1.65 1.65 2.03	1.13 1.13 1.14 1.52 1.52 2.02 2.03 2.03 2.03 2.78 2.78 2.78 2.78	10.4 11.6 12.9 17.0 19.5 25.1 28.3 33 39.3 49.4 53.7 59.1 66.5	3.5 3.5 3.5 5.5 5.5 5.5 7.0 7.0 7.0 8.0 8.0 8.0 10.0	9.42 5.30 3.40 2.36 1.32 0.84 0.497 0.309 0.184 0.120 0.0940 0.0736 0.0575	2,500 2,000 2,000 1,500 1,500 1,500 1,000 1,000 800 800 800 600 600	142 200 271 431 649 971 1,533 2,270 3,604 5,560 6,906 8,769 11,121	300 300 300 300 300 300 300 300 300 300 200 200 200

The Aobest 0.6/1kv xlpe insulated pvc sheathed power cable is always produced under our most advanced
technology in the feild, and tested by professional third authorities, ensuring the best quality and long working period. The 0.6/1kv xlpe insulated pvc sheathed power cable can be produced according to clients' special requests. For the materials of the 0.6/1kv xlpe insulated pvc sheathed power cable, we choose pure copper as conductor and fine insulation XLPE, with strong application advantages.

Aobest company can also produce many other PVC/XLPE power cable,rubber cable,control cable,ABC cable,bare AAC/AAAC/ACSR conductor. More info needed, pls contact me freely.

Photo of the 0.6/1kv xlpe insulated pvc sheathed power cable
