Control Cable Flame-retardant instrumentation cable 450/750V~0.6/1kV

Price:	0.2~100.0 USD
Payment Terms:	T/T,L/C,WU,
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: KYJV

Production Capacity: 50000 kilometers one week

Delivery Date: within 15 days for one cont...

Insulation Material: XLPE

type: control cable

voltage: 450/750v

Means of Transport: Ocean,Land,Air,

Packing: Export standard steel woode...

Shielding: Braid

Brand Name: aobest

insulation: xlpe/pe

1 IEC, ASTM, DIN, BS standard
2 ISO,CCC certification
3.Rated voltage 450/750V
4.Jacket:PVC
5.Chemical corrosion resistance

Copper ConductorFire-resistance

1.Characteristics and Applications of the Products:

Plastic insulated control cable is used to connect electricalequipments. It applies to controlling, monitoring and protective system withA.C. rated voltage U₀/U up to and including 450/750v.

The main features of the flame retardant PVC control cable ishard to get fire or that the continuous buring of cables is very limited when itis on fire .It applies to the places with special demands of flame retardantproperty.

Fire resistant cable can operate normally for some time whenit is burning except that is transmit electrical power under normal condition.Itis used in the places necessary to resist fire.

2.Operating characteristics:

(1)The long-time permissible operating temperature is 70^oC;

The ambient temperature under installation should not go below0^oC.

(2)a. for non-armoured cable and flexible shielded cable, the bendingradius should not be less than 6 times the outer diameter;

b. for armoured or copper-tape shielded cable, the bending radiusshould not be less than 12 times the outer diameter;

Model	Description	Application
KVV	copper conductor, PVC insulated, PVCsheathed, control cable	Suitable for being laid indoors, in cable trench, pipelines or other specificoccasions.
KVVP	copper conductor, PVC insulated, PVC sheathed, braided, shielded, controlcable	Suitable for being laid indoors, in cable trench, pipelines or other specificoccasions that demands shielding.
KVVP2	copper conductor, PVC insulated,PVCsheathed, copper-tape shielded,control cable
KVV22	copper conductor, PVC insulated, PVC sheathed, steel-tape armored, controlcable	Suitable for being laid indoors, in cable trench and pipelines, directlyburial or other specific occasions with a relatively large capacity formechanical stretching force.
KVV32	copper conductor, PVC insulated, PVC sheathed, thin steel wire-armored,control cable	Suitable for being laid indoors, in cable trench, pipelines, silo or otherspecific occasions that demands shielding.
KVVR	copper conductor, PVC insulated, PVCsheathed, flexible, controlcable	Suitable for being laid indoors and places that demands moving cables withflexibility.
KVVRP	copper conductor, PVC insulated,PVC sheathed, braided shielded, flexible,control cable	Suitable for being laid indoors and shielded places that demands movingcables with flexibility
