Copper-tape Screened Control Cable kvvp2 from China manufacturer - Zhengzhou Aobest Electronic Technology Co., Ltd.

Copper-tape Screened Control Cable kvvp2

Price:	0.2~100.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: control cable

Production Capacity: 50000 kilometers one week

Delivery Date: within 15 days

Insulation Material: XLPE

Conductor Material: Copper

type: control cable

core: multi

Means of Transport: Ocean,Land,Air

Packing: woodern drum

Shielding: Braid

Jacket: PVC

Brand Name: aobest

voltage: medium

insulation: xlpe

multicore copper pvc sheathed control cable
1.Copper-tape Screened
2.Manufacture direct sales
3.competitive price
4.Small quantity accepted

1.Standard

The control cable can be produced according to the standardGB9330-1988,IEC,DIN,BS,and the factory can also manufacture the cables inaccordance with other standards.

2.Scope of Application

The control cable are suitable for the wiring of electricalcontrolling equipments and instrument,monitoring and controlling returncircuit,electrical protection and measurement in power distribution unit underthe circumstance that the rated voltage is up to 450/750V AC.

3.Service Conditions

(1) The long-time working temperature of conductor of PVCinsulated cable is 70^oC

The long-time working temperature of conductor of XLPE insulatedcable is 90^oC

(2) The temperature for laying the cables can not be lower than0oC.Permissible bending radius(r):unarmoured cable:r≥6D;(D: outer diameter ofthe cable);armoured or copper-tape screened cable:r≥12D;shielded flexiblecable:r≥6D

4.Description

Type	Name
KVV	Copper conductor PVC insulated PVC sheathed control cable
KVVP	Copper conductor PVC insulated PVC sheathed braiding screened controlcable
KVVP2	Copper conductor PVC insulated PVC sheathed copper tape screened controlcable
KVVP3	Copper conductor PVC insulated PVC sheathed aluminum- plastic compound tapescreened control cable
KVV22	Copper conductor PVC insulated PVC sheathed steel tape armored controlcable
KVV32	Copper conductor PVC insulated PVC sheathed fine steel wire armored controlcable
KVVP2-22	Copper conductor PVC insulated PVC sheathed copper tape screened steel tapearmored control cable
KVVR	Copper conductor PVC insulated PVC sheathed flexible controlcable
KVVRP	Copper conductor PVC insulated PVC sheathed braiding screened flexiblecontrol cable
KVVP-22	Copper conductor PVC insulated PVC sheathed braiding screened steel tapearmored control cable
KYJV	Copper conductor XLPE insulated PVC sheathed control cable
KYJVP	Copper conductor XLPE insulated PVC sheathed braiding screened controlcable
KYJVP2	Copper conductor XLPE insulated PVC sheathed copper tape screened controlcable
KYJVP3	Copper conductor XLPE insulated PVC sheathed aluminum-plastic compoundscreened control cable
KYJV22	Copper conductor XLPE insulated PVC sheathed steel tape armored controlcable
KYJV32	Copper conductor XLPE insulated PVC sheathed fine steel wire armored controlcable
KYJVP2-22	Copper conductor XLPE insulated PVC sheathed copper tape screened steel tapearmored control cable
KYJVR	Copper conductor XLPE insulated PVC sheathed flexible controlcable
KYJVRP	Copper conductor XLPE insulated PVC sheathed braiding screened flexiblecontrol cable
KYJVP-22	Copper conductor XLPE insulated PVC sheathed braiding screened steel tapearmored control cable
