multi-cores instrumentation cable control cable from China manufacturer - Zhengzhou Aobest Electronic Technology Co., Ltd.

multi-cores instrumentation cable control cable

Price:	0.2~100.0 USD
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: control cable

Packing: woodern drum

Shielding: Braid

Jacket: PVC

Brand Name: aobest

voltage: medium

Production Capacity: 50000 kilometers one week

Delivery Date: within 15 days

Insulation Material: XLPE

Conductor Material: Copper

type: control cable

core: multi

multi-cores instrumentation cable
Voltage rating: 450/750V 600/1000 V
Standard:IEC,VDE, BS etc.
the best price quality&service.

Best sale controlcable multi-cores instrumentation cable
Application:

Itis suitable for connection of electric apparatus and instrument in electricitydistribution equipment
with A.C. rated voltage up to and including 450V/750Vor D.C.1000V.

Standard:

The cable ismanufactrued according to GB9330-88 or IEC 227 (1979).

Operationcharacteristic:

The permissible operating temperature of conductor shallnot exceed 70°C

when the cable is used for long period, The cable shallbe installed at temperaure
not less than 0 °C . The bending radius shall notbe less than 6D (without
copper tape and steel tape armouring) and 12D (withcopper tape and steel tape
armouring)respectively. D:overall diameter of cable.

Type anddescription:

Type	Name	Mainapplications
KVV	Copperconductor PVC insulated and sheathed control cable	For layingindoors, in trenches and in ducts, for fixed installation
KVVP	Copperconductor PVC insulated and sheathed copper wire braiding screened controlcable	For layingindoors, in trenches and in ducts, for fixed installation
KVVP2	Copperconductor PVC insulated and sheathed control cable with steel tapeshield	For layingindoors, in trenches and in ducts, for fixed installation
KVV22	Copperconductor PVC insulated and sheathed control cable with steel tapearmored	For layingindoors, in trenches, in ducts and in ground, able to withstand heaviermechanical force, for fixed installation
KVV32	Copper conductorPVC insulation and sheath control cable with steel wirearmored	For laying indoors,in cable furrow, pipe, shaft with demand on enduring strong mechanical force
KVVR	Copperconductor PVC insulated flexibe control cable	For layingindoors, movable and flexible
KVVRP	Copper conductorPVC insulated and sheath control cable with braiding shielded	Forlaying indoors with demand on shielding and softness

Note: 1: We also produce flame retardant cable according tothe
requirements of customer. Prefix "ZR-" should be added.Eg: ZR-KVV
type
2: We also produce cablewhich does not belong to standard type
according to therequirement of customer. Eg. KVVP2-22,KVVP32.

VariousSpecification Range

type	Ratedvoltage	mm2Nominal cross sectional area
		0.5	0.75	1		1.5	2.5	4	6	10
		Numberof cores
KVV	450/750V		2-61					2-14		2-10
KVVP			2-61					2-14		2-10
KVVP2 KVVP3			4-61					4-14		4-10
KVV22			7-61			4-61	4-61	4-14		4-10
KVV32			19-61			7-61	7-61	4-14		4-10
KVVR		2-61
KVVRP		2-61					2-48
KVVP-22			7-61		4-61			4-14		4-10
KVVP2-22			7-61		4-61			4-14		4-10
